This is for all of you with 06 Civics who plan on getting the fogs but would prefer to do it yourself on the install (I'm sure the labor quote isn't a pretty one). Note: This guide is based on an Si, and may be slightly different for other trims. If you have any questions, please refer to the instruction manual provided with the kit.
Feel free to ask any questions or for more in depth detail on any step. And if you have any other suggestions or comments to add please post them up as well! Hope you find this helpful. Oh yea, please excuse the dirty car!
Disclaimer: These are the pics I took of nearly almost every step while following the provided installation guide. These pics are not a substitute for the actual installation instructions and should not be treated as such. They are only for a visual tool to aid and assist you in your installation. I am not responsible if you mess up along the way.
There are 30 pics in all.
EDIT: The following image is looking up under the dash while lying on your back. The fuse box would be to the right and the center console to the left from this view.
Awesome install guide. I'll be referencing it in the near future. Do the fog lights in this configuration light when the main headlights are off or do they only work when their on?
Edited by Sprecher (01/17/0606:08 AM)
_________________________
'06 Honda Civic Si Habanero Red /Navi #5130
If you do the install as shown above, the fogs will only receive power when the low beams are on. Any other state (DRL, parking lights, high beams) they will turn off.
They can be rewired to work however you like, either constant power, or perhaps using the parking lights (so they are on in all lighting states except when they're off and only DRL's are running).
As soon as I learn the wiring of this car, I will write up some ways to modify this WITHOUT cutting or splicing wires, etc. On my experience with 94-01 Integras, there were several one pin connectors on the fuse box to choose from to plug your accesory into. It was easy as that. On this car there is only the single 6-pin accesory plug, so it will have to be rewired elsewhere. I need a Helms/Haynes to learn the wiring, but I will update this soon.
Hope this helps, please feel free to ask more questions!
Registered: 02/13/00
Posts: 29137
Loc: Wall St ....NYC
looking good
_________________________
My Grandmother told me that there was a passage in the bible that says, "It is better to spill your seed in the belly of a whore, than to spill it on the ground." So, I tried both. And the bible's right! It's way better. That's one of the reasons they call it the good book.”
Registered: 02/13/00
Posts: 29137
Loc: Wall St ....NYC
Quote: amazing write up. although it doesnt seem as though im gonna attempt this install like the 99-00 install! Id rather get it done laziness ownz me.
for being an old fart like me
_________________________
My Grandmother told me that there was a passage in the bible that says, "It is better to spill your seed in the belly of a whore, than to spill it on the ground." So, I tried both. And the bible's right! It's way better. That's one of the reasons they call it the good book.”
how does the appearance look in real life? its it bright enough for a person like me? and also how much did you pay for those. i know they cost a lot of money about $650 in canadian dollars...
as for how they look, I believe they are 55W bulbs (they are H11) and match the lowbeams perfectly in terms of brightness and color. As for vision and field enhancement, I'll take some pics next time I get the chance to show the beam pattern, but I showed a few people last night and it's nuts. If the low beams let you see out between 11 and 1 (imagine a clock face), then the foglights let you see 10 and 2.
This is the type of post that we used to get on the 99-00 Si. I used to print them out and use them for all of my installs. Beautiful write up and nice pictures. Great Job
Great Write up! Keep us posted on how to power them via the park lights or always on. I had Honda install mine (Yeah they actually threw in the Fogs and Labor as a counter-offer when i was trying to beat them down under MSRP), but i'd like to rewire them myself.
Quote: Great Write up! Keep us posted on how to power them via the park lights or always on. I had Honda install mine (Yeah they actually threw in the Fogs and Labor as a counter-offer when i was trying to beat them down under MSRP), but i'd like to rewire them myself.
that is something i should do too... in canada its about 25 xxx and with taxes and stuff it would come out to about 27000 but they marked it up to 29xxx! i think that is bull shit because if i plan to get even the fog lights or HFP body kit the price of the SI would easily go over 30 grand... 30 grand for a civic is just retarted
_________________________ I'll fly you out to Vegas and buy your hookers and blow if Michigan doesn't beat OSU this year. -Dwalk "I single win bet on Big Brown is actually a money losing wager. His odds right now are 2/5. So, if you bet 5 you only win 2 so you lose 3."-The_Rhino
I was wondering if you could tell me what is on the back of the factory fog light switch? I want to hook up an aftermarket kit to the factory switch, but I need 3 prongs: power, ground, and fog light wire.
Also does there look to be like a good place to mount aftermarket lights? and after cutting open the holes, would it look alright / be easy to file down the edges to make a smooth opening - since my foggers would not go around the whole plastic area.
Quote: If you do the install as shown above, the fogs will only receive power when the low beams are on. Any other state (DRL, parking lights, high beams) they will turn off.
They can be rewired to work however you like, either constant power, or perhaps using the parking lights (so they are on in all lighting states except when they're off and only DRL's are running).
As soon as I learn the wiring of this car, I will write up some ways to modify this WITHOUT cutting or splicing wires, etc. On my experience with 94-01 Integras, there were several one pin connectors on the fuse box to choose from to plug your accesory into. It was easy as that. On this car there is only the single 6-pin accesory plug, so it will have to be rewired elsewhere. I need a Helms/Haynes to learn the wiring, but I will update this soon.
Hope this helps, please feel free to ask more questions!
it's not possible to do it, honda uses a bus system on the car, and unless you can re program the computer that controls the fogs you are not going to be able to do this. pretty much you'll have to manually rewire the fogs by hand to do this
How did you get the harness through the firewall? is there a nice, open grommet?
The car comes from the factory wired for fogs, you just have to plug them into the existing empty harness in front of the passenger's side wheel well. Then just connect a few wires inside the car. The main harness is routed from the front of the car to the fuse box already. (for all the other lights and sensors up front)
Great write up by the way!
_________________________
Fiji Blue Pearl Civic Si #1367
My car came in this week. I had the car for about an hour and already had the car apart installing the fogs. These cars def need the fogs - those plastic ovals looks stupid.
With the help of this thread, the install was pretty easy.
_________________________
Fiji Blue Pearl 06 Si non-navi (#4247)
Registered: 02/27/06
Posts: 144
Loc: South Carolina, Florence, U.S.
Badass write up man great work!
